Alpha E-Tec Plus 28NX, 33NX and 38NX - Commissioning
6.10 USER INFORMATION
The User must be advised (and demonstrated if necessary) of the following important points:-
1. How to light and turn off the boiler and how to operate the system controls.
2. The importance of annual servicing of the boiler to ensure safe and efficient operation and maintain the boiler
guarantee.
3. That any servicing or replacement of parts must only be carried out by a Gas Safe registered engineer.
4. Ensure that the boiler controls and room thermostat (if fitted) are set to the User's requirements.
5. Tell the User about the sealed system pressure.
6. Tell the User that if the electrical supply is on and the boiler has not operated for 24 hours for heating or hot water, the
pump will automatically operate for 30 seconds.
7. Explain to the User that an internal frost thermostat is fitted in the boiler, and that the electrical supply to the boiler must
be left on for the thermostat to operate, i.e. the boiler must be set to standby.
8. Explain to the User that in certain weather conditions the flue terminal will emit a plume of steam, i.e. water vapour. This
is safe and quite normal.
9. Show the User the position of the condensate discharge pipes.
10. Leave the instructions with the User.
11. Ensure the Benchmark Checklist at the back of these instructions has been completed after the boiler has been
installed and commissioned.
Note: It is a requirement that the installation is registered by the installer through the Gas Safe Gas Work Notification Scheme.
12. Leave these Installation and Servicing instructions with the User for use on future calls.
6.11 INFORMATION MENU
Press the 'INFO' button (item 3 in Fig. 6.1) for at least1second for the 'Information menu' to open, displaying some
boiler operation parameters.
To scroll through the various parameters press the 'INFO' button, then press 'MODE' button to enter the parameter and show
the value.
To go back to the previous screen or exit the menu, press the 'RESET' button (item 4 in Fig. 6.1), or wait 15 minutes.
Parameter ID
d.0
d.1
d.2
d.3
d.4
d.5
d.6
d.7
d.8
d.9
d.10
d.11
d.12
d.13
d.14
d.15
d.16
d.17
d.18
d.19
d.20
d.21
d.22
d.23
d.24
d.25
d.26
d.27
Description
Flowsmart temperature adjustment (with optional diverter kit only)
Displays the flame signal (μA)
Displays the primary heat exchanger output instant heating ow temperature (°C)
Displays the instant output temperature from the DHW heat exchanger (°C)
Displays the values set for central heating set (°C)
Displays the values set for the DHW set (°C)
Displays the external temperature (if optional external probe tted). If it is below zero, the value is displayed ashing (°C)
Displays the temperature of the inlet DHW (if optional DHW inlet probe tted) (°C)
Displays the system return temperature (°C)
Displays a list of the last eight faults (to scroll the list, press the CH temperature up or down buttons, items 7 or 8 in Fig. 6.1)
Fault list reset. Once d.10 is displayed, press MODE, the display shows '--'. Thenpress MODE again for at least 3 seconds.
Deletion is conrmed via the '88 88' symbols ashing for 2 seconds
Not used
Displays the pump operating speed
Not used
Displays the pump ow rate (l/h)
Displays the fan operating speed (rpm)
Displays the temperature read by the ue sensor (°C)
Displays the calculated ow temperature (°C)
At the end of the screed heater function, displays for how many hours the ow temperature remained at 'Top set'
Toggles between the safety software version and the functional software version
Not used
Not used
System pressure (bar)
Not used
Not used
Not used
Not used
Not used
