103448-07 - 1/16 45
IV. Venting D. Stainless Steel Venting (continued)
Vent System Component
Part Numbers
Equivalent Feet of
Pipe
ALP080B - 210B ALP285B
3" Vent 4" Vent
SS Vent Kit 102501-01 102501-02
N/A
Horizontal Vent Terminal
(Included in Kit)
8116310 8116313
PVC to SS Vent Adapter
(Included In Kit)
102219-01 102220-01
Vertical Vent Terminal 102680-01 102680-02 N/A
Pipe x 1 Ft. 8116296U 100176-01 1
Pipe x 3 Ft. 8116298U 100177-01 3
Pipe x 5 Ft. 8116300U 100178-01 5
Pipe x Adjustable 8116319U 100179-01
Equal to
Installed Length
(1.06 to 1.64)
90° Elbow 8116294U 100180-01
5.5 (3")
8.0 (4")
45° Elbow 8116292U 100181-01
4.0 (3")
4.5 (4")
Horizontal Drain Tee 8116302U 100182-01 2
Vertical Drain Tee 8116304U 100183-01 7½
Single Wall Thimble 8116116 100184-01 N/A
Table 10A: U.S. Boiler Company Vent System Components (Stainless Steel)
Manufacturer
Vent
System
Nominal
Diameter
Boiler Adapter
Horizontal
Termination &
Screen
Vertical
Termination &
Screen
Wall Thimble
M&G/DuraVent FasNseal
2” N/A N/A N/A N/A
3”
FSA-HFB3
(WALL MTD)
FSA-PVC3
(FLOOR MTD)
FSELB9003 &
FSBS3
FSVL (*) 03 & FSBS3 FSWT3
4”
FSA-PVC4
(FLOOR MTD)
FSELB9004 &
FSBS4
FSVL (*) 04 & FSBS4 FSWT4
Z-Flex Z-Vent™
SVE Series III,
Z-Vent III
2” N/A N/A N/A N/A
3”
2SVSHF03
(WALL MTD)
2SVSTTA03
(FLOOR MTD)
2SVSTPF03 2SVSTEX0390 2SVSWTF03
4”
2SVSTTA04.5
(FLOOR MTD)
2SVSTPF04 2SVSTEX0490 2SVSWTF04
NOTE: See approved Manufacturer’s literature for other required component part numbers (straight pipe, elbows, restops,
vent supports etc.).
Table 10B: Stainless Steel Vent Systems and Terminations (Installer Provided)
Approved for Optional Horizontal or Vertical Termination
