You can flexibly customize the unit to suit your own preferences and
usage. Choose the SETUP menu from GENERAL Setting, TUNER
Setting, etc., to select your desired setting.
1 Press MENU to select the SETUP mode, then press
MODE.
BASS ENGINE SETUP RETURN (OFF) BASS ENGINE
2 Press or to select the desired item, then
press MODE.
(e.g. Select AUDIO)
GENERAL TUNER AUDIO DISPLAY DEMO
The SETUP menu of the selected item is displayed.
3 Press or to select the desired SETUP
menu, then press MODE.
(e.g. Select Subwoofer)
GENERAL
Birthday Set Clock Mode Clock
Clock Adjust*
1
Illumination Play Mode
Beep INT Mute AUX IN (AUX Name)*
2
Digital AUX Power IC Birthday Set
TUNER
FM Level RDS Regional*
3
PI Seek*
4
Auto Clock*
5
Alert PTY31*
6
FM Level
AUDIO
Subwoofer (SUBW. System)*
7
Subwoofer
DISPLAY
Dimmer Scroll Type Text Scroll
Font Select Language Set BGV Select
Opening MSG Calendar Dimmer
DEMO
DEMO
*
1
Refer to “Setting the Time and Calendar” (page 7).
*
2
Displayed only when AUX IN is ON.
*
3
Refer to “Receiving RDS Regional (Local) Stations” (page 9).
*
4
Refer to “PI SEEK Setting” (page 9).
*
5
Refer to “Setting the Time to automatically Adjust” (page 9).
*
6
Refer to “Setting PTY31 (Emergency Broadcast) reception” (page 9).
*
7
Displayed only when Subwoofer is ON.
4 Turn the Rotary encoder to change the setting.
(e.g. Select Subwoofer ON or Subwoofer OFF.)
5 Press MENU to select RETURN.
After 2 seconds the unit returns to normal mode.
Pressing and holding MENU for at least 2 seconds will
return to normal mode.
GENERAL is selected on the setup main menu in step 2.
Birthday Opening Message Setting (Birthday Set)
By inputting your birthday details, a message can be displayed on that
day.
Turn the Rotary encoder to set “mm” (Month), then press MODE . Turn
the Rotary encoder again to set “dd” (Date), then press MODE again.
Setting the Clock Display (Clock Mode)
You can select the clock display type, 12-hour or 24-hour, depending on
your preference.
Turning the Clock Display ON/OFF
When ON is set, the time always appears in the lower left of the display.
Changing Lighting Colour
CDA-9857R:
Illumination Blue (Initial setting) / Red
CDA-9856R:
Illumination Green (Initial setting) / Red
You can change the lighting colour of the buttons.
CDA-9857R:
Blue Red
CDA-9856R:
Green Red
Playing MP3/WMA Data (Play Mode)
This product can playback CDs containing both CD and MP3/WMA data.
However, in some situations (some enhanced CDs), playback may be
difficult. For these special cases, you can select playback of a single
session only, containing the CD data. When a disc contains both CD or the
MP3/WMA data, playback starts from the CD data portion of the disc.
• Perform this setting before inserting a disc. If a disc has already been
inserted, perform the setting after you remove the disc. (If you use an
MP3 changer, you have to change discs.)
Sound (Beep) Guide Function
This function will give audible feedback with varying tones depending
upon the button pressed.
Turning Mute Mode On/Off (INT Mute)
If a device having the interrupt feature is connected, audio will be
automatically muted whenever the interrupt signal is received from the
device.
SETUP
A typical SETUP procedure is shown in steps 1 to 5 as
follows. See below for further information about each
SETUP menu.
SOURCE/POWORRotary encoder
MODE
MENU
BAND
General Setting
mm/dd
AM (Before noon) 12:00 (12HOUR) / 00:00 (24HOUR)
(Initial setting)
Clock ON (Initial Setting) / Clock OFF
CD-DA (Initial setting) / CDDA&MP3/WMA
CD-DA : Only the CD data in Session 1 can be
played back.
CDDA&MP3/WMA :Both CD data and MP3/WMA file tracks on a
mixed mode, multi-session disc can be
played back.
BEEP ON (Initial setting) / BEEP OFF
INT Mute ON (Initial setting) / INT Mute OFF
