Adjusting Volume
Turn the
Rotary encoder
until the desired sound is obtained.
Setting the Time and Calendar
1
Press MENU to select the SETUP mode, then press
MODE.
BASS ENGINE SETUP RETURN (OFF) BASS ENGINE
2
Press or to select the GENERAL mode,
then press MODE.
3
Press or to select the “Clock Adjust”,
then press MODE.
4
Turn the Rotary encoder to set year.
5
Press MODE.
6
Repeat steps 4 and 5 above to set month, day, hour
and minutes.
7
Press MENU to select RETURN.
After 2 seconds, the unit returns to normal mode.
Pressing and holding MENU for at least 2 seconds will
return to normal mode.
• To synchronize the clock to another clock/watch or radio time
announcement, press and hold MODE for at least 2 seconds after
setting the “hour.” Minutes will reset to 00. If the display shows over
“30” minutes when you do this, the time will advance one hour.
Listening to Radio
1
Press SOURCE/POWER to select the TUNER mode.
2
Press BAND repeatedly until the desired radio band
is displayed.
FM1 FM2 FM3 MW LW FM1
3
Press TUNE/A.ME to select the tuning mode.
DX (Distance mode) LOCAL (Local mode)
MANUAL (Manual mode) DX
• The initial mode is Distance mode.
Distance mode:
Both strong and weak stations will be automatically tuned in
(Automatic Seek Tuning).
Local mode:
Only strong stations will be automatically tuned in (Automatic
Seek Tuning).
Manual mode:
The frequency is manually tuned in steps (Manual tuning).
4
Press or to tune in the desired station.
Holding down or will change the frequency
continuously.
Manual Storing of Station Presets
1
Select the radio band and tune in a desired radio
station you wish to store in the preset memory.
2
Press and hold, for at least 2 seconds, any one of the
preset buttons (1 through 6) into which you wish
to store the station.
The selected station is stored.
The display shows the band, preset number and station
frequency memorized.
• A total of 30 stations can be stored in the preset memory (6 stations
for each band; FM1, FM2, FM3, MW and LW).
• If you store a station in a preset memory which already has a station,
the current station will be cleared and replaced with the new station.
• If the audio function mode is activated, press FUNC. to return to
preset mode.
Controllable With Remote Control
The CDA-9857R/CDA-9856R can be controlled with an
optional Alpine remote control. For details, consult your
Alpine dealer.
Point the optional remote control transmitter at the remote
control sensor.
Connectable to Remote Control Interface Box
This unit may be controlled from the vehicle’s audio controls.
An optional Alpine Remote Control Interface Box must be
used. For details, contact your Alpine dealer.
Remote control sensor
Radio
SOURCE/POWER
TUNE/A.ME
BAND
MODE
Preset buttons
(1 through 6)
Rotary
encoder
FUNC.
