25-EN
*9 The setting items are the same as iPod setting in SETUP
mode. For details, refer to “iPod/iPhone Search Mode
Setting” on page 28.
*10 AUX NAME can be selected in this mode. For details, refer to
“Setting the AUX NAME mode” on page 27.
*11 FW VERSION can be selected in this mode. You can see the
current firmware version about BLUETOOTH by using this
setting.
*12 CALL SOUND, CALLER ID, PB UPDATE, PB ORDER,
AUTO ANS, SEV NAME, SPEAKER SL and FW VERSION
can be selected in this mode. For details about these settings,
refer to “BLUETOOTH SETUP” on page 30.
*13 The Hands free phone talk level, ring tone level and
microphone gain level can be adjusted by using this setting.
The setting values in Option mode and in SETUP mode are
linked. Refer to “Adjusting the volume (VOL LV ADJ)” on
page 31.
*14 Refer to “Setting the BLUETOOTH sound quality” on
page 31.
*15 While calling, the call sound can be switched between the
unit and Smartphone by using this setting.
This operation can also be done by pressing BAND. Refer to
“Call Switching Operation” on page 35.
*16 While calling, and the Voice Mute is activated, the
microphone input will mute instantly and “VOICE MUTE”
will blink. This operation can also be done by pressing .
Refer to “Muting the microphone input quickly (Voice Mute)”
on page 35.
*17 If there is a waiting call, select this item to display the caller’s
Name and waiting number (1 or 2). Press VIEW and the
display will switch.
*18 Select this item to hang up the call.
Applying TuneIt
This unit’s sound tuning is programmable from a connected
Smartphone. It is also possible to download specific parameters for
certain vehicles from Alpine’s TuneIt database stored in the Cloud. Using
the TuneIt App, customized parameters can also be uploaded for others
to share and rate.
Through this unit, it is also possible to receive and respond to
information from Alpine’s Social Network Service (SNS) available
through the connected Smartphone.
The installed TuneIt App should be launched on the Smartphone before
connection to the head unit.
TuneIt, is downloadable from Apple’s App Store; the Android user can
download it from Google Play. For details, consult your Alpine dealer.
Before these operations, set ALPINE APP to USB or BT depending on
the connected Smartphone. For details, refer to “Setting the
communication mode with a Smartphone (ALPINE APP)” on page 29.
Notes
• The application programme and related specifications and data may be
deleted or terminated without notice.
• Some TuneIt functions may not be available if the Smartphone is not in
a service area or receives no signal.
After setting the above procedure, you can adjust the unit’s sound
function on the Smartphone.
1
Make sure the unit is powered on.
2
Launch the TuneIt App on the Smartphone. Adjust the
unit’s sound accordingly on the Smartphone.
During sound setting, VSOURCE key may blink.
Notes
• Volume and sound parameter preset function cannot be adjusted via
the Smartphone.
• The setting cannot be done on both the Smartphone and this unit at the
same time. While the sound function of this unit is set via the
Smartphone, sound function settings on CDE-177BT will be displayed
as “APPCONNECT”.
• When the unit is powered off or during a call, sound setting cannot be
done via the Smartphone.
• This function may not be available depending on the paired
Smartphone.
• Please obey all local traffic laws while using this function.
Some functions may be available in a future version of TuneIt.
Note
• Depending on the paired Smartphone, the following functions may not
be available even though the TuneIt version is updated.
Receiving Notification (Ready on future update)
When the Smartphone connected to this unit receives notification from
Facebook, it will BEEP and the VSOURCE key blinks (depending on
the TuneIt settings on the phone). At the same time, the user’s name is
shown in the display (20 characters maximum).
1
While receiving Notification from Facebook, press
VSOURCE button.
Notification Menu screen is displayed.
2
Turn the Rotary encoder to select the desired mode, and
then press ENTER.
LIKE
*1
REPLAY NEXT PREVIOUS TTS VOLUME
*2
*1 Not displayed when the received Notification is Message type.
*2 It can also be set in SETUP section. For details, refer to “Setting
the TTS (Text To Speech) volume” on page 29.
Notes
•Press t to return to the previous mode.
• A new received Notification prompt will last for 30 seconds. If there is
no operation within 30 seconds, the unit will return to normal mode.
• When this unit is powered off, during a call or receiving RDS
interruption information, Notification of the Smartphone will not be
prompted by this unit.
Adjusting the sound via the Smartphone
Facebook Notification Function
LIKE: The Smartphone feedbacks to Facebook with “Like”,
and meanwhile, the received Wall Posts or
Comments are played back by TTS (Text To
Speech).
REPLAY: To play back Notification by TTS (Text To Speech)
again.
NEXT: To select the next Notification.
PREVIOUS: To select the previous Notification.
TTS VOLUME: To adjust the playback volume of TTS (Text To
Speech).
To Next Page
