43-EN
The CD is being improperly inserted.
Make sure the CD is being inserted following instructions in the
CD Player Operation section.
Unable to fast forward or backward the CD.
The CD has been damaged.
Eject the CD and discard it; using a damaged CD in your unit can
cause damage to the mechanism.
CD playback sound skips due to vibration.
Improper mounting of the unit.
Securely re-mount the unit.
The disc is very dirty.
–Clean the disc.
The disc has scratches.
Change the disc.
The pick-up lens is dirty.
Do not use a commercially available lens cleaner disc. Consult
your nearest Alpine dealer.
CD playback sound skips without vibration.
The disc is dirty or scratched.
Clean the disc; damaged disc should be replaced.
Error displays (built-in CD player only).
Mechanical error
Press . After the error indication disappears, insert the disc
again. If the above-mentioned solution does not solve the problem,
consult your nearest Alpine dealer.
CD-R/CD-RW playback not possible.
Close session (finalisation) has not been performed.
Perform finalisation and attempt playback again.
MP3, WMA or AAC is not played back.
Writing error occurred. The MP3/WMA/AAC format is not
compatible.
Make sure the MP3/WMA/AAC has been written in a supported
format. Refer to “About MP3/WMA/AAC” on page 16, then
rewrite in the format supported by this device.
The sound is not output from the speakers.
Unit has no output signal of the internal amplifier.
POWER IC is switched to “ON”, refer to “Connecting to an
External Amplifier (POWER IC)” on page 19.
iPod does not play and no sound is output.
The iPod has not been recognised.
Reset this unit and the iPod. Refer to “Initial System Start-Up” on
page 10. To reset the iPod, refer to the Owner’s Manual of the iPod.
•No CD is inserted.
–Insert a CD.
Although a disc is inserted, “NO DISC” is displayed and the unit does
not start to play or eject the disc.
Remove the disc by following these steps:
Press the button again for at least 2 seconds.
If the disc still does not eject, consult your Alpine dealer.
Mechanism error.
1 Press the button and eject the CD.
If not ejecting, consult your Alpine dealer.
2 When the error indication remains after ejecting, press the
button again.
If the error indication still does not turn off after pressing the
button for a few times, consult your Alpine dealer.
When “ERROR” is displayed:
If the disc cannot be ejected by pressing , press the RESET switch
(refer to “Initial System Start-Up” on page 10) and press again.
If the disc still cannot be ejected, consult your Alpine dealer.
A copy-protected WMA file was played back.
You can only play back non-copy-protected files.
A sampling rate/bit rate not supported by the unit is used.
Use a sampling rate/bit rate that is supported by the unit.
Database error or decoder error.
You can solve the problem by switching the source.
Communication error or boot error, etc.
You can solve the problem by reconnecting the USB Memory,
changing source or format the USB memory.
Abnormal current is run to the USB Flash Memory device.
You can solve the problem by switching the source.
A USB Memory is not connected.
Make sure the USB Memory device is correctly connected.
No song (file) is stored in the USB memory.
Connect the USB memory device after storing songs (files).
A sampling rate/bit rate not supported by the unit is used.
Use a sampling rate/bit rate that is supported by the unit.
MP3/WMA/AAC
Audio
iPod
Indication for CD Player
Indication for USB Memory
NO USB DEVICE

Table of Contents

Other manuals for Alpine CDE-177BT

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Alpine CDE-177BT and is the answer not in the manual?

Alpine CDE-177BT Specifications

General IconGeneral
MP3 playbackYes
Audio formats supportedAAC, MP3, WMA
AM band range531 - 1602 kHz
FM band range87.5 - 108 MHz
LW band range153 - 281 kHz
Supported radio bandsFM, LW, MW
Preset stations quantity30
DIN size1 DIN
Output power200 W
RDS featuresAF, PTY, TA, TP
Product colorBlack
Volume controlRotary
Disc types supportedCD, CD-R, CD-RW
Equalizer bands quantity9
Signal-to-Noise Ratio (SNR)65 dB
Mobile operating systems supportedAndroid, iOS
Display typeLED
Display technologyLCD
Display number of lines2 lines
USB version2.0
Bluetooth version2.1+EDR
Bluetooth profilesA2DP, AVRCP, HFP, HSP, SPP
USB ports quantity1
Bluetooth functionsAudiostreaming, Handsfree calling
Audio inputAUX
Menu languagesDEU, DUT, ENG, ESP, FRE, RUS
Output voltage2 V
File format systemFAT 16/32
Compatible productsiPod touch 4th/3rd/2nd/1st Gen., iPod nano 6th/5th/4th/3rd/2nd/1st Gen., iPod classic 160GB/120GB/80GB, iPhone 4S, iPhone 4, iPhone 3GS, iPhone 3G and iPhone\\r Compatible for iPhone and Android Smartphones: Available on Apple App Store and Google Play Store
Disc playback modesRandom, Repeat track
Key illumination colorMulti
Weight and Dimensions IconWeight and Dimensions
Weight1400 g
Dimensions (WxDxH)178 x 50 x 161 mm
