43-EN
Other Useful Features
Setting Front/Rear/Subwoofer Preout
of the External Expansion Box
You can use Front/Rear/Subwoofer Preout with
the optional expansion box (KCE-104V). Set to
ON to use KCE-104V preout.
1 When the monitor is open, press and hold
MUTE/SETUP for at least 2 seconds. The
SETUP screen appears.
2 Press preset 5 to activate the SYSTEM setting
mode. Press preset 5 again to select EXPAND
PREOUT.
3 Press g or f to select ON or OFF.
Select ON to use the preout (Front/Rear/
Subwoofer) of the optional expansion box (KCE-
104V).
For any other settings, press preset 5 or another
preset button.
4 After setting is completed, press MUTE/SETUP
to return to normal mode.
CAUTION
Make sure that the preout of the external expansion box
is set to OFF when using the CVA-1004R internal
amplifier. Note that if the preout is set to ON, the volume
level will be too high.
Displaying Spectrum Analyzer
When using the optional expansion box (KCE-
104V), you can use this function.
1 When the monitor is open, press and hold
MUTE/SETUP for at least 2 seconds. The
SETUP screen appears.
2 Press preset 5 to activate the SYSTEM setting
mode. Press preset 5 again to select SPE.ANA.
3 Press g or f to select ON or OFF.
Set to ON, then press V.SEL to select the
Spectrum Analyzer display (refer to
“Simultaneous Operation” on page 46).
For any other settings, press preset 5 or another
preset button.
4 After setting is completed, press MUTE/SETUP
to return to normal mode.
NOTE
When an external Audio Processor is connected,
Spectrum Analyzer is displayed only in FM/MW/LW
mode.
