17-EN
Sound Setting
Adjusting Bass/Treble/Balance (Between Left and
Right)/Fader (Between Front and Rear)/Defeat
1
Press Rotary encoder repeatedly to choose the
desired mode.
Each press changes the modes as follows:
BASS → TREBLE → SUBWOOFER* → BALANCE → FADER
→ DEFEAT → VOLUME → BASS
Bass : -7 ~ +10
Treble : -7 ~ +7
Subwoofer : 0 ~ +15
Balance : L15 ~ R15
Fader : R15 ~ F15
Defeat : ON/OFF
Volume : 0 ~ 35
• If the Rotary encoder is not pressed within 5 seconds after
selecting the BASS, TREBLE, BALANCE, FADER, DEFEAT or
SUBWOOFER mode, the unit automatically returns to normal
mode.
* When the subwoofer mode is set to OFF, its level cannot be
adjusted.
2
Turn the Rotary encoder until the desired sound
is obtained in each mode.
By setting Defeat ON, previously adjusted settings of
BASS and TREBLE will return to the factory defaults and
BBE is turned off.
• Depending on the connected devices, some functions and display
indications do not work.
Tips
Switching from the disc menu.
For some discs, the audio language, angle and subtitles can be
switched from the disc menu.
1 Press MENU, select the item, then press ENT.
2 Press 8, 9, ; or : to select the language or angle,
then press ENT.
(For some discs, they can be selected using the
number keys “0” to “9” while the language or the angle
menu is displayed.)
Displaying the Disc Status (DVD only)
Use the procedure described below to display the status (title number,
chapter number, etc.) of the currently playing DVD on the monitor
screen.
• This operation is controlled using the remote control unit.
During playback, press DISP/TOP M.
The playback status is displayed.
The playback status display closes when DISP/TOP M. is
pressed again.
Displaying the Disc Status (Video CD only)
Use the procedure described below to obtain an on-screen display of
the status (track number, etc.) of the currently playing video CD on
the monitor screen.
• This operation is controlled using the remote control unit.
During playback, press DISP/TOP M.
The playback status is displayed.
The playback status display closes when DISP/TOP M. is
pressed again.
• When PBC is set to ON, the current track number and track
playback time is not displayed.
TV system
(NTSC or PAL)
Playback disc
Current title
number
Current chapter
number
Chapter
playback time
Current audio
language/number
Repeat setting
(Default setting -
REPEAT OFF)
Current subtitle
language/number
Current angle
number
1181
LAP
T
:
EP
Y
EAROFF
AUD I O ENG 1 / 4
DOL BY 2 . 1D3 /
:23'45"
:
SUBT . J
:
ANGLE
PN 1 / 2
1/3
DVD–V I DEONTSC
Playback status
Current audio
signal output
SOURCE/
POWER
g
f
BAND Rotary encoder
CENTER f.
TV system
(NTSC or PAL)
Playback disc
Current track
number
Tr ack playback
time
Repeat setting
(Default setting -
REPEAT DISC)
Playback control
(PBC)
Playback status
1
LAP
T
EP
Y
EARDIS
PBC
12 ' 34"
VIDEO–CD NTSC
OFF
C
To Next Page
