53-EN
– – – – – – – –
• The user has selected a channel number that does not exist or
is not subscribed to.
- The unit will revert back to the previously selected channel.
• There is no artist name/feature, song/program title, or
additional information associated with the channel at that time.
- No action needed.
Indication for iPod Mode
• The iPod is not connected.
- Make sure the iPod is correctly connected (refer to
“Connections”).
Make sure the cable is not bent excessively.
• The iPod’s battery remains low.
- Refer to the iPod’s documentation and charge the battery.
• There are no songs in the iPod.
-Download songs to the iPod and connect to the adapter.
• Communication error
-Turn the ignition key off, and then set to ACC or ON again.
- Check the display by reconnecting between the iPod and the
adapter, using the iPod cable.
• Caused by the iPod Software Version not being compatible
with the optional adapter KCA-420i.
- Refer to the Owner’s Manual of the optional adapter KCA-
420i, and update the iPod Software Version to be compatible
with the optional adapter KCA-420i.
NO IPOD
ERROR-01
NO FILE
ERROR-02
CAUTION-Laser radiation when open, DO NOT STARE INTO BEAM
(Bottom side of player)
Specifications
FM TUNER SECTION
Tuning Range 87.7 – 107.9 MHz
Mono Usable Sensitivity 9.3 dBf (0.8 µV/75 ohms)
50 dB Quieting Sensitivity 13.5 dBf (1.3 µV/75 ohms)
Alternate Channel Selectivity 80 dB
Signal-to-Noise Ratio 65 dB
Stereo Separation 35 dB
Capture Ratio 2.0 dB
AM TUNER SECTION
Tuning Range 530 – 1,710 kHz
Sensitivity (IEC Standard) 22.5 µV/27 dB
CD/DVD SECTION
Frequency Response 5 – 20,000 Hz (±1 dB)
Wow & Flutter (% WRMS) Below measurable limits
Total Harmonic Distortion 0.008% (at 1 kHz)
Dynamic Range 95 dB (at 1 kHz)
Channel Separation 90 dB (at 1 kHz)
Signal system NTSC
Horizontal resolution 500 lines or greater
Video output level 1Vp-p (75 ohms)
Video S/N ratio DVD: 70 dB
Audio S/N ratio 115 dB
PICKUP
Wave length DVD: 665nm
CD: 800nm
Laser power CLASS II
REMOTE CONTROL
Battery Type CR2025 battery
Width 51 mm (2")
Height 119 mm (4-11/16")
Depth 13 mm (33/64")
Weight
50 g (1.75 oz) (battery excluded)
GENERAL
Power Requirement 14.4 V DC
(11–16 V allowable)
Power Output 16 W RMS × 4*
* Primary amplifier ratings per CEA-2006 Standard
•Power output: measured at 4 Ohms and ≤ 1% THD+N
• S/N: 80 dBA (reference: 1 W into 4 Ohms)
Maximum Pre-Output Voltage 2 V/10 k ohms
Bass + 20 dB/– 14dB at 100 Hz
Treble ± 14 dB at 10 kHz
Weight 1.6 kg (3 lbs. 8 oz)
CHASSIS SIZE
Width 178 mm (7")
Height 50 mm (2")
Depth 160 mm (6-1/4")
NOSEPIECE SIZE
Width 170 mm (6-11/16")
Height 46 mm (1-13/16")
Depth 18 mm (11/16")
• Due to continuous product improvement, specifications and design
are subject to change without notice.
