2
Touch [] after setting to ON.
The Media Xpander setup screen appears.
3
Touch [] or [] of the desired MX mode.
• Music source (such as radio broadcasts and CDs, excluding AM
radio) level can be set.
MX CD (OFF, CD MX 1 to 3)
CD mode processes a large quantity of data. This data is used
to reproduce the sound cleanly by making use of the data
quantity.
MX CMPM (OFF, CMPM MX 1 to 3)
This corrects information that was omitted at the time of
compression. This reproduces a well-balanced sound close to
the original.
MX FM (OFF, FM MX 1 to 3)
The medium to high frequencies become more clear, and
produces well balanced sound in all the bands.
MX DVD (OFF, MOVIE MX 1 to 2)
The dialog portion of the video is reproduced more clearly.
MX AUX (OFF, CMPM MX, MOVIE MX, MUSIC MX)
Choose the MX mode (CMPM, MUSIC, or MOVIE) that
corresponds to the media connected.
• When OFF is selected, MX effect of each MX mode will be OFF.
• Each music source, such as radio, CD and MP3/WMA/AAC can have
its own MX setting.
• MX mode does not function when MX is ON for AM radio.
• MX CMPM is applied for MP3/WMA/AAC and iPhone/iPod.
• The MX setting can be performed only when a source is currently
selected.
You can modify the Equalizer settings to create a response curve more
appealing to your personal taste.
Setting item: P-EQ
1
Select L+R by touching [ ] of P-EQ.
When graphic EQ is set to L+R, the setting will be turned off.
2
Touch [] of P-EQ after selecting L+R.
The P-EQ list screen appears.
3
Adjust the P-EQ to your preference.
Adjusting the Band
Touch [ ] or [ ] of BAND to select the band to be adjusted.
BAND1 / BAND2 / BAND3 / BAND4 / BAND5
Adjusting the Frequency
Touch [] or [] of Freq. to adjust the frequency of the
selected band.
Adjustable frequency bands:
20 Hz to 20 kHz (in 1/3 octave steps)
Band-1: 20 Hz~80 Hz (63 Hz)
Band-2: 50 Hz~200 Hz (150 Hz)
Band-3: 125 Hz~3.2 kHz (400 Hz)
Band-4: 315 Hz~8 kHz (1 kHz)
Band-5: 800 Hz~20 kHz (2.5 kHz)
Adjusting the Level
Touch [] or [] of Level to adjust the level of selected
band.
Adjustable level: –6 to +6 dB
Setting the Bandwidth
Touch [] or [] of Q to select the bandwidth.
Adjustable bandwidth: 1, 1.5, 3
4
To adjust another band, repeat step 3 and adjust all
bands.
• The frequencies of adjacent bands cannot be adjusted within 4 steps.
• While adjusting the Parametric EQ, you should consider the
frequency response of the connected speakers.
• When the parametric EQ is adjusted, the adjustment for graphic EQ
becomes ineffective.
You can modify the equalizer settings to create a response curve more
appealing to your personal taste.
Setting item: G-EQ
1
Select L+R by touching [] of G-EQ.
When parametric EQ is set to L+R, this setting will be turned
off.
2
Touch [] of G-EQ after selecting L+R.
The G-EQ list screen appears.
3
Adjust the G-EQ to your preference.
Adjusting the Band
Touch [] or [] of BAND to select the band to be adjusted.
BAND-1 (63 Hz) / BAND-2 (150 Hz) / BAND-3 (400 Hz) /
BAND-4 (1 kHz) / BAND-5 (2.5 kHz) / BAND-6 (6.3 kHz) /
BAND-7 (17.5 kHz)
Adjusting the Level
Touch [] or [] of Level to adjust the level of selected
band.
Adjustable output level: –6 to +6 dB
4
To adjust another band, repeat step 3, and then
adjust all bands.
• When graphic EQ is adjusted, the adjustment for parametric EQ
becomes ineffective.
You can change the unit, (cm or inch) of time correction.
Touch [ ] or [ ] of T.Corr Parameter to select cm or Inch.
Setting item: T.Corr Parameter
cm Inch
(DVD MUSIC)
This disc contains a large quantity of data such as music clip.
MX uses this data to reproduce the sound accurately.
Adjusting the Parametric Equalizer Curve
(P-EQ)
Adjusting the Graphic Equalizer Curve
(G-EQ)
Setting the Time Correction Unit (T.Corr
Parameter)
cm: The unit of time correction is cm.
Inch: The unit of time correction is Inch.
