Excell MCDSe series
Rel. 1
alsa apparecchi medicali srl 15
Type of Error
Code
Code memorized in E
2
PROM
(in CAL mode, select “ 0d ”)
1
Errors of setting or on the activation circuits
Anomaly on the neutral plate
no nP
-
Error registered into the neutral plate circuit
Err nPC 81
Error on the control circuit of the plate/tissue contact
Err 53 35
Error on the hand-switch activation circuit at the switching on
Err Hnd 82
Error on the pedal-switch activation circuit at the switching on
Err PEd 83
Simultaneous activation of two devices not allowed
USr Act 85
Error on the keyboard registered during the self test
Err 14 0E
Errors on the Argon gas section
Input pressure of the Argon gas too high
HI PrS 88
Error in the Argon gas section during the Argon selection
Err 30 1E
Loss of Argon gas due to an internal leakage
Err 31 1F
Pressure of the Argon gas not sufficient during the activation
Err 29 1d
Activation of the Argon input placed backside during the
switching on
Err Ein 84
Errors on the Master microcontroller
RAM memory
Err 32 20
FLASH memory
Err 34 22
Complemented variables of the system
Err 35 23
Errors on the power supply section
Watchdog Timer
Err 33 21
Error +5V
Err 36 24
Error of the R.F. power supply with lower setting value
Err 37 25
Error of the R.F. power supply with higher setting value
Err 38 26
R.F. power supply higher than the pre-set value during the
activation phase
Err 97 61
Errors on the serial communication
Error on the serial communication peripherals placed on the
main board (Alsa code: 801463)
2 slow acoustic
repetitions and then rapid
intermittence
3d
Error on the serial communication peripheral placed on the
power supply board (Alsa code: 801471)
3 slow acoustic
repetitions and then rapid
intermittence
3E
1
According to the numerical indication of error which appears on the display when an anomaly occurs, the hexadecimal value
correspondent to one of the Error Codes shown in the column Code is memorized inside the E
2
PROM.
