Packaging -- Transport and Storage
Packing -- Marking -- Storage
P22--0001EN/02
3/4
01--2011
© ALSTOM 2010. All rights reserved. Information contained in this document is indicative only. No representation or warranty is given or should be
relied on that it is complete or correct or will apply to any particular project. This will depend on the technical and commercial circumstances. It is
provided without liability and is subject to change without notice. Reproduction, use or disclosure to third parties, without express written authority, is
strictly prohibited.
GRID
Marking o f sub--assemblies and packaging.
Introduction
Each individual circuit breaker component (pole, operating mechnism, etc.)
is identified by a plate.
The IDs of each element are marked on the package.
Example of
markings and
indications.
-- N ° Manufacturer’s reference = 101 525
-- Circuit breaker No.1
-- P o l e n ° 2
101 525 0010
n
o
SERIE
Ozn. 01/2
101 525 0010
n
o
MANUFACTURER’S
REFERENCE
POLE N
o
MARKING ON
PACKAGING
MARKINGS ON
SUB--ASSEMBLIES
AND TOOLING
1
2
0101
ID N
o
FOR CIRCUIT BREAKER
CASE N
o
COVERED BY THE ID
Location of
plates
Select and assemble the components identified by the plate(1) and
sticker(3).
101 525 0010
n
o
SERIE
Ozn. 01/2
EXTERIOR PLATE
INTERIOR PLATE
1
3
To Next Page
