Installation
Tightening torque values
P31--0001EN/02
3/4
01--2011
© ALSTOM 2010. All rights reserved. Information contained in this document is indicative only. No representation or warranty is given or should be
relied on that it is complete or correct or will apply to any particular project. This will depend on the technical and commercial circumstances. It is
provided without liability and is subject to change without notice. Reproduction, use or disclosure to third parties, without express written authority, is
strictly prohibited.
GRID
Torque tightening values
Table of values
The tightentening tool and method must ensure the torque actually applied
to the screw head corresponds to the torque in the following reference
table with a tolerance of ± 20%.
TIGHTENING TORQUE VALUES
in daN.m
STEEL SCREW
CLASS 6.8
or
STAINLESS A2--70, A4--70
STAINLESS A2--80, A4--80
CLASS 8.8
M2,5 0,05 0,06
M3 0,09 0,11
M4 0,19 0,26
M5 0,38 0,51
M6 0,66 0,88
M8 1,58 2,11
M10 3,20 4,27
M12 4,97 6,63
M14 8,67 11,56
M16 13,42 17,90
M20 26,22 34,98
M24 45,68 60,93
M30 90,44 120,65
