Description and Functionalities
General Description of the Switchgear
P12--0001EN/02
1/6
01--2011
© ALSTOM 2010. All rights reserved. Information contained in this document is indicative only. No representation or warranty is given or should be relied on
that it is complete or correct or will apply to any particular project. This will depend on the technical and commercial circumstances. It is provided without
liability and is subject to change without notice. Reproduction, use or disclosure to third parties, without express written authority, is strictly prohibited.
GRID
GL314 P circuit breaker
with FK3--07 spring operating system
Description
The device comprises three poles actuated, respectively, by three spring
operating mechanisms.
Illustration
D
C
A
B
Table of Elements
The following table lists the main components of the circuit breaker :
Mark Component Page
A Circuit breaker pole 2
B Support frame 3
C Operating mechanism 4
D Cable box 5
