Installation
Calculating the SF
6 gas filling pressure
For u sing th e pressure gau g e (tools)
P31--9001EN/02
2/4
01--2011
© ALSTOM 2010. All rights reserved. Information contained in this document is indicative only. No representation or warranty is given or should be
relied on that it is complete or correct or will apply to any particular project. This will depend on the technical and commercial circumstances. It is
provided without liability and is subject to change without notice. Reproduction, use or disclosure to third parties, without express written authority, is
strictly prohibited.
GRID
Technical data
SF
6
gas
The following table gives the characteristics of the SF
6
gas:
Absolute pressure
at 20°C
p
re
Absolute filling pressure for insulation 0.75 MPa
For a relative pressure
at 20°C and101.3 kPa
p
re
Assigned relative filling
pressure for insulation
+0,01
-- 0
0,65 MPa
p
ae
Relative alarm pressure for
insulation
+0,02
-- 0
0,54 MPa (p
me
+0.03 MPa)
p
me
Minimum relative insulation
pressure
+0,02
-- 0
0,51 MPa
Density of SF6 gas
p
re
49.59 kg/m
3
p
ae
41.66 kg/m
3
p
me
39.55 kg/m
3
Minimum permissible temperature
up to
-- 3 0 °C
Example
Determination of the filling pressure in SF
6 gas for a circuit breaker .
Parameters Values
p
re
Assignedrelative filling
pressure for insulation
in SF
6
gas
0,65 MPa
(94.27 psi)
Ambient Temperature 5°C
Local atmospheric pressure 93,2 kPa
Filling with
SF
6
gas
The following table gives the steps for calculating the filling pressure for
SF
6
gas:
Step
Action Result
1 In the table (page 4) ”Relative
pressure values for
SF
6
gas
corrected for temperature,” read
the value p
re
situated in the
range t°C=5.
0,603 MPa
2 Calculate the atmospheric
pressure variation :
0,1013 -- 0,0932
0,0081 MPa
3 Calculate the assigned relative
pressure p
re
for 5°C:
0,603 + 0,0081
0,6111 MPa
4 The filling takes place at the
assigned pressure, increaed by
0.01 MPa so:
0,6111 + 0,01
Filling with SF
6
gas
0,621 1 MPa
