2
embedded processor
• Bag of six rubber (silicon) covers for the DE1 board stands. The bag also contains some
extender pins, which can be used to facilitate easier probing with testing equipment of the
board’s I/O expansion headers
• Clear plastic cover for the board
• 9V DC wall-mount power supply
1.2 The DE1 Board Assembly
To assemble the included stands for the DE1 board:
• Assemble a rubber (silicon) cover, as shown in Figure 1.2, for each of the six copper stands
on the DE1 board
• The clear plastic cover provides extra protection, and is mounted over the top of the board
by using additional stands and screws
Figure 1.2. The feet for the DE1 board.
1.3 Getting Help
Here are the addresses where you can get help if you encounter problems:
• Altera Corporation
101 Innovation Drive
San Jose, California, 95134 USA
Email:
university@altera.com
