COMPONENTS
Ve ctor F® Se ries ▪ S ervice Ma nual ▪ M N- 46 89 5 ▪ R ev 1 ▪ 7/ 20
42
Circuit Breakers
Ref. Description Ref. Description
1 Chamber 1 heating elements 4 Chamber 4 heating elements (F4 only)
2 Chamber 2 heating elements 5 Control voltage
3 Chamber 3 heating elements 6 Control voltage
1
2
3
4
56
