PRODUCT DESCRIPTION
2. PRODUCT DESCRIPTION
The control units of CU-TR series are designed to use as part of industrial sectional doors and
to control components of the drive system of industrial doors. Direct application is operation
control of drives TR series*:
CU-TR230: TR-3531-230, TR-5024-230, TR-3531-230E, TR-5020-230E, TR-5024-230E
CU-TR400: TR-5024-400, TR-10024-400, TR-13018-400, TR-5013-400E, TR-5020-400E,
TR-5024-400E, TR-10024-400E, TR-13018-400E, TR-13012-400E
The drive system is a set of devices (electric drive, electric control unit, safety, control, light
indication, sensors) that control the door movement and ensure the safe operation of doors.
The control unit can be set to one of three operation (control) modes:
• Manual (manual operation mode is ON / setting P3–F1, Table 13). The doors will move only
when the control element (button) is held. Factory settings.
• Pulse (manual mode is OFF). Doors movement to opening or closing, or stop of the
movement are performed by pressing the control button for a short period (pulse signal).
• Automatic (manual mode is OFF and P4 automatic closing setting is ON). A one time pulse
control signal will lead to a full cycle of the doors movement: “opening — countdown of set
pause time till automatic closing — closing”.
Depending on the selected operation mode and the terms of use, the specialist determines
which control devices (key switch, remote control, etc.) and safe operation devices (safety mar-
gin, photocells, photolines, sensors) should be included into the drive system.
2.1 DELIVERY KIT
The delivery kit is shown in Figure 1.
Y
After receiving the product, make sure that the kit is complete and that the kit components are
not visibly damaged. In case of discrepancies, contact the supplier.
2.2 SPECIFICATIONS
Table 1
FEATURE CUTR230 CUTR400
Supply voltage 230V ± 10% ~ 400V ± 10% 3N~
Network frequency 50 Hz
Maximum drive power 1 kW 1.5 kW
Maximum power consumption in standby mode
(without additional devices)
3 W 4 W
Power supply for additional devices
12V DC / max.150 mA
24 V DC / max.250 mA
Cross section of wires connected to connectors max.2.5 mm
Radio control
433.92 MHz ± 0.075MHz / dynamic code /
maximum of 32 remotes
Protection degree IP65 (professional installation)
Operating temperature range −20° … +50°
Gross weight 2.7 kg 2.9 kg
* Drives with encoder are with the designation E.
Drives with mechanical end position switches are without designation E.
