CONTROL UNITS UTR230 / UTR400 9797
SETTINGS
Settings of menu P2:
F1…F3 — remote control command(s) record (Table 5, Table 6)
F4, F5 — changing the control command(s) of the recorded remote control (Table 7, Table 8)
F6 — determination of the remote control numbers (Table 9)
F7 — determination of the recorded remote number (Table 10)
F8, F9 — remote control deleting (Table 10, Table 11)
F0 — deleting all remotes (Table 12)
Table 4 describes the radio control commands and the numbering of control commands ispre-
sented in menu P2.
Table 4
CONTROL COMMAND
SETTINGS
F1F5
MEANING
NO COMMAND Control command is not set 00
STEP BYSTEP (ENTRY)
Performing actions of opening, stopping movement,
closing. The sequence of actions is set by
settingP3–F3 (Table 13). When conguring the outputs
of connectors7–9 (Table 2) for two-way control operation
(settingsP3–F4…F6, Table 13), the ENTRY or EXIT
direction is determined
01
STEP BYSTEP (EXIT) 07
OPEN (EXIT)
Performing of opening. When setting the outputs of
connectors 7–9 (Table 2) for two-way control operation
(settings P3–F4…F6, Table 13), the ENTRY or EXIT
direction is determined
02
OPEN (ENTRY) 06
PARTIALLY OPEN
From the fully closed door position, the opening is
performed within the time set in P1–F9 (Table13)
05
CLOSE Performing of closing 03
STOP Performing of movement stop 04
LIGHTING (TURN ON)
Performing either TURN ON or TURN OFF, or TURN ON /
OFF when setting the outputs of connectors 7–9 (Table2)
for lighting operation (settings P3–F4…F6, Table 13).
Automatic turn o (operating time) of lighting is set by
setting P8–F4
08
LIGHTING (TURN OFF) 09
LIGHTING ( TURN ON / OFF) 10
LOAD 1 (TURN ON)
Performing either TURN ON or TURN OFF, or
TURN ON / OFF when setting the outputs of connectors
7–9 (Table 2) to control external load 1 or 2 (settings
P3–F4…F6, Table13). Automatic turn o (operating time)
of the load is set by the settings P8–F7 (LOAD 1) and
P8–F8 (LOAD2)
11
LOAD 1 (TURN OFF) 12
LOAD 1 ( TURN ON / OFF) 13
LOAD 2 (TURN ON) 14
LOAD 2 (TURN OFF) 15
LOAD 2 ( TURN ON / OFF) 16
