Pega 367 with Fanuc 04PC User Pre-installation Guide ©Amada America, Inc.
Print Date 03/07/2001 Revision 4.0 This document available on the World Wide Web at http://www.amada.com Page 6 of 35
Specifications - Motion Package
Travel Method X and Y axes work piece movement
Control Method X, Y, T & C
Drive Motors Fanuc AC Servo (X, Y, T, C)
Maximum Sheet Size 60" (Y) x 144" (X) with one repositioning cycle. Additional support tables are
required for material lengths greater than 72”
Maximum Sheet Thickness 0.250"
Maximum Material Weight 264 lb.
Maximum Axis Travel 72.0" (X) by 60" (Y)
Max. Table Speed ( X / Y / Combined ) 1,968 IPM / 1,968 IPM / 2,783 IPM
Punching Accuracy ±0.004"
Positioning Accuracy ±0.001"
Repeatability ±0.001"
Specifications - Punching System
Press Capacity 33 Tons
Press Stroke 1.259"
Stroke Per Minute 350
Maximum Hit Rate 1” Centers 200
Maximum Hole Diameter 4.500"
Tool Type Amada Thick Turret
Turret Rotation Speed 30 RPM
Feed Clearance 0.787"
Auto Index Rotation Speed 60 RPM
