Welcome to the Amana Family
Your purchase of an Amana refrigerator/
freezer -- a household appliance known
for its quality and reliability --is sin-
cerely appreciated by Amana Refrigera-
tion, Inc. Your total satisfaction with this
new product is extremely important to
us, and this Use and Care Manual will
aid you in understanding the operation
of your new appliance.
Each product is thoroughly tested and
checked at the factory Once in your
home, you may want to make a few sim-
ple adjustments of control settings, etc.,
to tailor your new unit to your own indi-
vidual requirements. These adjustments
are easily made following the instruc-
tions in this manual.
Should your new unit ever require serv-
ice, certain product information will aid
in obtaining service faster! For your con-
venience and protection, please record
this information in the box at right and
retain this booklet for future reference.
The Registration Card in the packet
with the manual should be filled out and
returned to Amana Refrigeration, Inc. If
your registration card is missing, call
1-800-843-0304 or write:
Consumer Affairs
Amana Refrigeration, Inc.
Dept. 800
Amana, Iowa 52204
Record in the space below
the information found on the
nameplate of your refrigerator.
The nameplate is located on
the ceiling of the refrigerator
section. Also, please retain a
copy of your sales receipt for
future reference should war-
ranty service be needed.
Serial No
Model No.__
Manufacturing No.__
Selling Dealer__
Recognize this symbol as a safety precaution
, ,WARNING
Electrical Grounding Instructions--This appliance is equipped with a three-prong (grounding) plug for
/our protection against possible shock hazards. Where a two-prong wall receptacle is encountered, it is
the personal responsibility and obligation of the customer to contact a qualified electrician and have it
replaced with a properly grounded three-prong wall receptacle in accordance with the National Electrical
Code (seefigure.)
Unit is designed to operate on a separate 103to 126 V.A.C., 15 amp., 60 cycle line.
DO NOT UNDER ANY CIRCUMSTANCES CUT OR REMOVE THE ROUND GROUND-
ING PRONG PROM THE PLUG. THE UNIT MUST BE GROUNDED AT ALL TIMES. DO
NOT REMOVE WARNING TAG FROM THE SERVICE CORD.
ELECTRICAL PLUG ELECTRICAL RECEPTACLE
, WARNING
DO NOT USE A TWO-PRONG ADAPTER,
,DO NOT USE AN EXTENSION CORD.
Contents Page
Electrical Warning ............... 2
Unpacking and Door Handle
Removal .................... 3
Door Assembly Removal .......... 5
Leveling, Door Alignment
and placement ............... 9
Ice 'N WaterTM Dispenser .......... 10
General Features ............... 14
Dimensions .................... 16
Setting the Controls ............. 17
Checking the Controls ............ 18
Touchmatic Electronic Controls ..... t9
Refrigerator Features (All Models) ... 25
ROUND GROUNDING PRONG
Contents
Page
Refrigerator Features
(27 Cu. Ft. Models) ............ 28
Refrigerator Features
(19,20, 22 & 25) .............. 31
Freezer Features ................ 32
Optional Features ............... 33
Non-Use Periods ................ 34
Sounds ....................... 35
Care and Cleaning .............. 36
Save Energy .................... 37
Before Calling for Service ......... 38
Amana Asure .................. 39
Amana Toll-Free ................ 39
