Amana DS01E User Manual

6
THE SPACE FROM THE TOP OF
THE MAGNET HOLDER AND THE BOTTOM
OF THE 01E OR DD01F
CANNOT BE MORE THAN 1/8”.
The ideal spacing allows a business
card to be easily placed
between the D 01E sensor
and the magnet holder.
DD
D OR DD01F
DOOR TRIM
MAGNET
DOOR
1/8” max.
MAGNET MUST BE 15/16”
FROM THE SENSOR
MOUNTING PLATE
MAGNET HOLDER MAY EXTEND
ABOVE THE DOOR
(OR THE DD01E OR
MAY EXTEND BELOW
THE DOOR FRAME)
TO ENSURE THE MAGNET IS NO MORE
THAN 1/8” FROM THE
BOTTOM CENTER OF THE SENSOR
DD01F
Security Screw
location (located
on each side of sensor)
SIDE VIEW
P
O
S
I
T
I
O
N
A
P
O
S
I
T
I
O
N
B
P
O
S
I
T
I
O
N
C
MAGNET SLOTS
MAGNET HOLDER
TOP VIEW
INSTALL THE MAGNET IN
THE CORRECT SLOT.
15/16th” FROM BACK EDGE OF
SENSOR MOUNTING PLATE
TO BACK OF MAGNET.
ALIGNMENT
GUIDES
ON SIDES
OF THE
MAGNET
HOLDER
Straight edge screwdriver
may be placed in slots
for magnet removal
Select one of the three slots that places the magnet 15/16” from the sensor mounting plate on the door frame. See
following examples. The door frame and door usually will not align. Place holder on the door and select the slot that
places the magnet as close as possible to the 15/16” depth from the back of the mounting plate.
