6
2. Press and then immediately release the white tactile
button on the back of the DS01* thermostat. should
now be displayed on the PTAC LED display. If does
not show on the display in 1-2 seconds, then press and
release the white button a second time. Skip this step if
there is no thermostat.
3. Press and then immediately release the white tactile
button on the back of the DD01* motion sensor. or
should now be displayed on the PTAC LED display.
If or does not show on the display in 1-2 sec-
onds, then press and release the white button a second
time. NOTE: If both a DD01* and a DS01* are being bound,
then the display will show .
Skip if there is no motion sensor.
4. Press “OFF” on the PTAC touchpad to exit the binding
sequence.
5. Snap thermostat onto thermostat mounting plate.
6. Snap motion sensor onto motion sensor mounting plate.
7. Configure the device or devices that were bound. See the
next section for configuration choices.
NOTE: If a wireless device is replaced or added, all
devices (including those previously bound) will need to
be bound/re-bound to the unit. See directions above.
Binding of RF Devices
DO NOT ATTEMPT TO BIND
MORE THAN ONE ROOM AT A TIME AT THE
SAME PROPERTY!!!
RF TRANSMITS THROUGH WALLS.
The wireless devices (DS01* and or DD01*) must be bound
to the PTAC DT01* control for proper in-room communica-
tion. Ensure the unit is powered but in the OFF position.
NOTE: Both the DS01* and the DD01* must be bound to
the PTAC unit during the same “learn” opera-
tion.
If you need to rebind one device - then you
must rebind both devices during the same
learn mode event.
All must be bound at one time.
1. Press and hold off button on the PTAC until appears.
To Next Page
