Amarex KRT
*: Installation type D only
***: Specific sizes only
①: Washers 550.06 eliminate axial play
Table54: Key to the symbols and codes
Symbol Description
Always apply a liquid sealing agent (e.g. Hylomar SQ32M) to sealing
surfaces marked with this symbol.
Table55: List of components
Part No. Description Part No. Description
101 Pump casing 66-2 Cooling jacket
163 Discharge cover 80-1 Motor unit
23-2 Auxiliary impeller 81-18.03 Cable terminal
230 Impeller 81-29.03 Terminal
260.01 Impeller hub cap 81-45 Float switch
320 Rolling element bearing 81-92.23 Cover plate
330 Bearing bracket 812 Motor housing cover
350 Bearing housing 818 Rotor
360 Bearing cover 900.04 Bolt/screw
411.01/.26/.34 Joint ring 901.20 Hexagon head bolt
412.01/.02/.03/.04/.06/.
12/.15/.17/.45/.46/.47/.
50/.51
O-ring 902.01/.27 Stud
421.02/.03 Lip seal 903.01/.34/.52 Screw plug
471.53 Seal cover 914.01/.02/.87 Hexagon socket head cap screw
500.05 Ring 920.01/.27 Nut
503 Impeller wear ring 932.02/.20/.32/.47 Circlip
512.02/.03 Wear ring 940.01/.02 Key
550.49/.87 Disc 950.02 Spring
647 Grease regulator
