The system allows for the configuration of up to 6 different time periods. Click the checkbox to the left of
the time period to enable that time period. Click the text next to each period to edit the time
period. To copy time periods, click the checkboxes next to the days of the week that you would like to
copy the settings to. Once finished on this screen, click Save to return to the time period settings screen.
Record Channel: This checkbox allows the user to enable the system to record video for that channel
when a motion detection alarm is triggered. Delay is also associated with this tab; it is the This field
specifies in seconds how long the delay between alarm activation and recording should be.
Picture Storage: When an alarm occurs, the NVR triggers a snapshot for the selected channel.
Tour: Allows the user to enable the camera to activate a PTZ tour when a motion detection alarm is
triggered.
PTZ Linkage: Allows the user to active PTZ functionality to an applicable PTZ device.
Alarm Tone: Check this box to enable an imported voice prompt to be used if an event occurs. To use this
feature, select a file from the dropdown box in the File Name section.
More: Allows the user to access other motion detection options:
Anti-Dither: This field allows the user to set the anti-dither time. The values in this field can range from 5
to 600 seconds. This time value controls how long the alarm signal lasts. Based on motion detection, a
buzzer can go off, a tour can begin, PTZ can be activated, a snapshot can be taken, or a channel can begin
recording.
Show Message: This checkbox allows the user to enable the system to show an on-screen message when
a motion detection alarm is triggered.
Buzzer: Check this box to enable a buzzer to be sound on your device if an event occurs.
Log: Check this box to enable a log of the abnormality to be retained into the system.
Send Email: This checkbox allows the user to enable the system to send an email when a motion detection
alarm is triggered.
To reset to default settings, click the Default button. To copy the motion detection settings, click on the
Copy to button. To refresh the page, click the Refresh button. To Save the settings click the Save button.
Video Loss
The video loss settings screen is where the NVR can be setup to notify the user any time there is video
loss on any of the channels.
Below is a description of the fields on the Video Loss settings page:
Channel: The channel dropdown menu is used to select which channel you would like to use to set your
motion detection.
Enable: This checkbox allows the user to enable the detection function for a specific channel. To select a
channel, click on the drop-down menu provided on the right.
Schedule: This setup button takes the user to the detection period settings screen. Below is a screenshot
of the motion detection period settings screen.
