AMD Hudson M1 Chipset User Manual

2
1-2 Specification
Spec Description
Design
z
3.5”SBC 6 layers; PCB size: 14.8x 10.2 cm
Chipset
z
Hudson M1 Chipset
Embedded CPU
z
Support AMD eOntario (G-Series) Dual core T56N 1.6GHz /
T40E 1.0GHz APU
Memory Slot
z
1 * DDRIII SODIMM Slot for un-buffered Single Channel
64-bit DDRIII 800/1066 SDRAM
z
Expandable to 8GB
Expansion Slots
z
CF card slot x1
z
Mini-PCI E slot x1 (Optional)
z
Mini-SATAIII slot x1(alternative with Mini PCI-E)
Integrate IDE
z
One PCI IDE controller that supports PCI Bus Mastering,
ATA PIO/DMA and the ULTRA DMA /100/66 functions that
deliver the data transfer rate up to 100MB/s.
LAN
z
Integrated Realtek RTL8111EVL PCI-E Gigabit LAN.
z
Support Fast Ethernet LAN function of providing
10/100/1000Mbps Ethernet data transfer rate
HD Audio
z
Realtek ALC662-GR 4-channel HD Audio Codec integrated
z
Audio driver and utility included
BIOS z
AMI 16MB Flash ROM
Multi I/O z
DVI-I connector x1
z
USB 2.0 port x 4 and USB 2.0 header x2
z
RJ-45 gigabit LAN connector x2
z
Audio Line out connector x1
z
SATAIII connector x2
z
Front panel header x1
z
RS422/485 header x2
