3
z
LVDS connector x1
z
GPIO connector x1
z
SYSTEM FAN header x1
1-3 Layout Diagram
DC12V
Power
Connector
USB 2.0
Connectors
DVI-I
Connector
USB 2.0
Connectors
RJ-45 LAN Connectors
Line-Out
Connector
