With power and other cabling unplugged, carefully align the PCBA stando holes to the sheet
metal tray (sener) standos. Next, it is suggested to insert two screws in opposite corners
of the board/tray combinaon. Loosely ghten the screws to aid in alignment. Add the
remaining seven screws and loosely ghten. Finally, in a le to right or right to le paern,
ghten all nine screws to 4.5 in-lbs.
Note: The tray will only t one direcon with the transceiver connectors having cutouts below. See Board
Component Descripons for more informaon.
