Table 17: Transceiver Mapping
VPK180 XCVP1802 LSVC4072 GTY/GTM Mapping
[UNUSED] ch3 GTM
Quad 124
X0Y22 BQ
[RN]
DCMAC
X0Y6
ILKN
X0Y2
GTM
Quad 224
X1Y22 CY
[LN]
ch3 [UNUSED]
QSFPDD_5 Lane 8 ch2 ch2 QSFPDD_6 Lane 8
[UNUSED] ch1 ch1 [UNUSED]
QSFPDD_5 Lane 7 ch0 ch0 QSFPDD_6 Lane 7
[UNUSED] refclk1 refclk1 [UNUSED]
8A34001 Q8 BUF0 refclk0 refclk0 8A34001 Q9 BUF0
[UNUSED] ch3 GTM
Quad 123
X0Y21 BP
[RN]
GTM
Quad 223
X1Y21 CX
[LN]
ch3 [UNUSED]
QSFPDD_5 Lane 6 ch2 ch2 QSFPDD_6 Lane 6
[UNUSED] ch1 ch1 [UNUSED]
QSFPDD_5 Lane 5 ch0 ch0 QSFPDD_6 Lane 5
[UNUSED] refclk1 refclk1 [UNUSED]
8A34001 Q8 BUF1 refclk0 refclk0 8A34001 Q9 BUF1
[UNUSED] ch3 GTM
Quad 122
X0Y20 BO
[RN]
(RCAL)
MRMAC
X0Y7
DCMAC
X1Y5
GTM
Quad 222
X1Y20 CW
[LN]
ch3 [UNUSED]
QSFPDD_5 Lane 4 ch2 ch2 QSFPDD_6 Lane 4
[UNUSED] ch1 ch1 [UNUSED]
QSFPDD_5 Lane 3 ch0 ch0 QSFPDD_6 Lane 3
[UNUSED] refclk1 refclk1 [UNUSED]
8A34001 Q8 BUF2 refclk0 refclk0 8A34001 Q9 BUF2
[UNUSED] ch3 GTM
Quad 121
X0Y19 BN
[RN]
MRMAC
X0Y6
GTM
Quad 221
X1Y19 CV
[LN]
ch3 [UNUSED]
QSFPDD_5 Lane 2 ch2 ch2 QSFPDD_6 Lane 2
[UNUSED] ch1 ch1 [UNUSED]
QSFPDD_5 Lane 1 ch0 ch0 QSFPDD_6 Lane 1
8A34001 CLK5 IN
MUX1
refclk1 refclk1 8A34001 CLK5 IN
MUX0
8A34001 Q8 BUF3 refclk0 refclk0 8A34001 Q9 BUF3
