CAUTION! Do NOT plug a PC ATX power supply 6-pin connector into the VPK180 board power
connector J16. The ATX 6-pin connector has a dierent pinout than J16. Connecng an ATX 6-pin
connector into J16 damages the VPK180 board and voids the board warranty.
The following gure shows the power connector J16, power switch SW13, and LED indicator
DS36.
Figure 22: Power Input
X27274-101222
Board Power System
[Figure 3, callout 18]
The VPK180 evaluaon board uses power management ICs (PMIC) and power regulators from
Inneon Integrated Circuits to supply the core and auxiliary voltages listed in the following tables.
The detailed ACAP connecons for the feature described in this secon are documented in the
VPK180 board schemac.
Chapter 3: Board Component Descriptions
UG1582 (v1.0) February 21, 2023 www.xilinx.com
VPK180 Board User Guide 67
