• PL GPIO connecons
○ PL UART1 to FTDI
○ PL GPIO DIP switch (4-posion)
○ PL GPIO LEDs (four)
○ PL GPIO pushbuons (two)
○ PL trace connector (J332)
○ PL SYSCTLR_GPIO[0:15]
○ PL 8A34001_GPIO[0:7, 10:15]
• 28 PL GTYP transceivers (7 quads)
○ Not used (18, bank GTYP102, GTYP103, GTYP104, GTYP105, GTYP106)
○ System controller HSDP (1, banks GTYP104)
○ USB-C HSDP (1, banks GTYP102)
○ FMCP1 HSPC DP (8, banks GTYP200, GTYP201)
• 140 PL GTM transceivers (35 quads)
○ Not used (74, bank GTM109, GTM110, GTM115, GTM116, GTM121, GTM122, GTM123,
GTM124, GTM202, GTM203, GTM204, GTM205, GTM206, GTM207, GTM212,
GTM213, GTM214, GTM215, GTM216, GTM217, GTM218, GTM219, GTM220,
GTM221, GTM222, GTM223, GTM224)
○ QSFPDD1 (8, banks GTM208, GTM209, GTM210, GTM211)
○ QSFPDD2 (8, banks GTM208, GTM209, GTM210, GTM211)
Note: QSFPDD1 and QSFPDD2 are interleaved.
○ QSFPDD3 (8, banks GTM111, GTM112)
○ QSFPDD4 (8, banks GTM117, GTM118)
○ QSFPDD5 (8, banks GTM121, GTM122, GTM123, GTM124)
○ QSFPDD6 (8, banks GTM221, GTM222, GTM223, GTM224)
○ OSFP (8, banks GTM214, GTM215, GTM216, GTM217)
○ SFPDD1 (2, bank GTM109)
○ SFPDD2 (2, bank GTM110)
○ SFPDD3 (2, bank GTM115)
○ SFPDD4 (2, bank GTM116)
