Installing Hardware
14 Intellex®
16-Channel
Alarms In Alarms Out
Pin No. Assignment Pin No. Assignment
1 Input 1 1 Output 1
2 Input 2 2 Output 2
3 Input 3 3 Output 3
G Ground G Ground
4 Input 4 4 Output 4
5 Input 5 5 Output 5
6 Input 6 6 Output 6
G Ground G Ground
7 Input 7 7 Output 7
8 Input 8 8 Output 8
9 Input 9 9 Output 9
G Ground G Ground
10 Input 10 10 Output 10
11 Input 11 11 Output 11
12 Input 12 12 Output 12
G Ground G Ground
13 Input 13 13 Output 13
14 Input 14 14 Output 14
15 Input 15 15 Output 15
G Ground G Ground
16 Input 16 16 Output 16
17 Time Sync COM Reserved
18 Export signal NC Reserved
G Ground NO Reserved
