Intellex IP
70 Intellex®
• Enable Bandwidth Limit — Can be set to On or Off
• Bandwidth Limit — Only applicable when Enable Bandwidth Limit is set to On. Meaasured in
KB/sec, with a range of 30 KB/sec to 400 KB/sec
13 Select OK to confirm the settings. The system will return to the IP Sources screen with a new
entry added for the configured IP Encoder. The device will be listed as an AD 4 Channel.
Changing an AD Device configuration
Once an IP Encoder had been added to the IP Sources both the IP Encoder configuration and the
device settings can be modified.
Modifying an IP Encoder’s configuration
1 From the main screen, select Setup.
2 Select IP Sources.
3 Highlight the required IP Encoder, then select Device Setup.
A new browser window will open displaying the IP Encoder Main Configuration Page. For more
information on configuring the IP Encoder see the IP Encoder Installation and User Guide.
Note
The Device Setup button can not be selected unless an AD device is highlighted.
Modifying an IP Encoder’s Device Setup
1 From the main screen, select Setup.
2 Select IP Sources.
3 Highlight the required IP Encoder, then select Edit.
The Configure AD Device screen will be displayed.
Note
The Edit button can not be selected unless an AD device is highlighted.
