Description
Page 16 of 60 Easy Ramp and EasyFlex Ramp
2.1.1 Floor section
The floor section (see Figure 1, page 15) offers sufficient
space for the passenger in the wheelchair. The surface of
the floor section is lower than the floor of the vehicle. This
ensures that the passenger has sufficient headroom.
2.1.2 Ramp
The Easy ramp is used in two positions.
In the completely deployed position, the ramp provides a
slope, via which the wheelchair can be easily pushed or
driven into the vehicle (see Figure 1, page 15).
The tailgate can be closed when the access ramp is in the
vertical position. The ramp leaves sufficient space for a pas-
senger or an empty wheelchair. In this position, the frame
of the access ramp fills the gap in the vehicle's rear bumper
(see Figure 2).
Figure 2
:
Easy Ramp in the Vertical Position
A third position is available for the EasyFlex ramp. The ramp
can be folded down into the vehicle. so that it is at the same
level as the floor of the vehicle (see Figure 3, page 17).
Ramp
Frame
