COLOURED MARKING ON THE MACHINE
COLOURED MARKING
Screw - top links: Yellow marks — 1. Loosing and following disassembly of this link
causes distinctive intervention to the mechanism
adjustment, that was done when assembled and
sewed off at the factory.
2. After such an intervention to the mechanism, new
adjustment of set mechanism needs to be done and
complete check of whole machine adjustment as
well.
Blue marks — Screws and nuts secured against loosing with glue
,,LOCTITE”.
Lubrication locations: Red marks — Caution: Lubrication regime adherance is
neces sary for protection of the reliable long-
term machine operation.
