2.BUTTONSANDINDICATORS



1.LNBINPUT:  Signalinputport,connectsdirectlytoantennausingcoaxialcable.

2.LCDScreen:   Showmenusandparameters.

3.ChargeLight:

Red:thebatteryisbeingcharged.

Blue:thebatteryisfull.

4.WarnLight:   FlashifLNBisshortconnected

5.WorkingLight:

Green:themeterisinwor

kingstatus

6.FunctionKeys:

F1:Turnon/offthescreendisplay

○
