APR 4920 APR 5920
1. Di men sions
B1
450 mm | 17.716 in
B2
600 mm | 23.622 in
B3
750 mm | 29.527 in
H1
ca. 1000 mm | 39.370 in
H2
817 mm | 32.165 in 850 mm | 33.464 in
H3
ca. 1285 mm | 50.590 in
L1
450 mm | 17.716 in 450 mm | 17.716 in
L2
898 mm
L3
ca. 1485 mm | 58.464 in ca. 1453 mm | 57.205 in
2. Weights
Base unit
391 kg | 862.01 lbs 440 kg | 970.03 lbs
w. mount. bra ckets 75 mm
413 kg | 910.51 lbs 461 kg | 1016.33 lbs
w. mount. bra ckets 150 mm
424 kg | 934.76 lbs 473 kg | 1042.79 lbs
Elec tri cal star ter
+15 kg | 33.07 lbs +17 kg | 37.48 lbs
3. Drive
En gine
Hatz 1B40
Type of con struc tion
1-cy lin der, four-stro ke die sel
Power out put
6.6 kW | 9.0 hp
Speed
2900 1/min
Cool ing
Air
Fuel capacitiy
5.0 l | 1.32 US gal
Fuel con sump tion
1.6 l/h | 0.42 US gal/h 1.6 l/h | 0.42 US gal/h
max. slop ing po si tion
25°
LM22020000-2 HbmG gnu thci dreV nna mmA 8102/20
2. Technical data
41
