8 Maintenance
BNNbOO
ID: 1138310 Issue date January 01, 2010
120
Removing the front water tank
Disconnecting the sprinkler hose
Hold the hose in your left hand and
press the black plastic ring (1) against
the screw connections with your right
hand.
You can now disconnect the hose.
ATTENTION!
Do not remove the hose without
pressing the ring against the screw
connection. The hose can get
damaged.
Draining water
Now let the water drain off until the
tank is completely empty.
Unscrewing the fastening screws
Unscrew the screw (1) of the intake
hose clamp (2).
1
2
1
