7 Options
BNNbOO
ID: 1138310 Issue date January 01, 2010
88
1-point lifting eye
If your roller is fitted with this option, you can lift the machine for transport
using the 1-point lifting eye as an alternative to the 4-point lifting eyes.
Articulated joint lock
WARNING!
Danger of crushing!
Before lifting, during transport of the
machine, you must install the lock
(1) of the articulated joint (joint
protection).
Lifting at the 1-point lifting eye
WARNING!
Accident hazard!
• Always lift the machine vertically.
• Personnel are not allowed below
suspended loads!
• Use only anti-slip, sturdy ramps
when loading!
• Secure the machine on the
transport vehicle to prevent it
rolling, slipping sideways or
overturning!
NOTE
The lifting devices (steel cables, etc.) must be dimensioned in accordance
with relevant regulations.
1
