5 Overview
BNNbOO
ID: 1138310 Issue date January 01, 2010
43
Component overview
1 Suspension
2 Engine oil filter
3 Hydraulic oil filter
4 Articulated joint protection
5 Hydraulic tank oil level indicator
(optical)
1 Hydraulic oil drain
2 Engine oil drain
3 Diesel tank drain
1 Water filter
2 Rear sprinkler
3 Roller drum scraper
4 Water pump (below the water
reservoir)
1
4
5
3
2
3
2
1
1
2
3
4
