Amped Wireless RTA15 - Technical Specification

RTA15
USER’S GUIDE
72
TECHNICAL SPECIFICATION
Wireless Standard: 802.11a/b/g/n/ac
Frequency Band: 2.4 GHz, 5.0GHz
Wireless Speed: 2.4GHz: 300Mbps (Tx/Rx)
5.0GHz: 867Mbps (Tx/Rx)
Amplifier: 2 x 2.4GHz 700mW Amplifiers
4 x 5.0GHz 700mW Amplifiers (2 Stage)
4 x Low Noise Amplifiers
Wireless Sensitivity: -94dBm
Wireless Output Power: Up to 29dBm
Wireless Security:
 WEP, WPA, WPA2, WPA Mixed, WPS
Processor Clock Speed: 660MHz
Wireless Coverage Control:
 15% - 100% Output Power
Antennas:
 1 x Detachable High Gain
2.4GHz 5dBi Antenna
 1 x Detachable High Gain
5.0GHz 5dBi Antenna
 1 x Detachable High Gain
Dual Band Antennas
 3 x Reverse SMA Connector
Ports:
 4 x RJ-45 10/100/1000 LAN ports
 1 x RJ-45 10/100 /1000 WAN ports
 USB 2.0 Port for Storage Devices
Mounting:
 Wall, Stand or Desktop
Warranty: 1 Year
Setup Requirements:
 Wired or wireless PC/Mac
 Google Chrome, Internet Explorer (8.0 and
up) or Safari web browser
