Amprobe ACD-14 PLUS - Page 16

13
Capacitance
Range
1)
Accuracy
2) 3)
500.0nF, 5.000μF, 50.00μF,
500.0μF, 3000μF
±( 3.5% rdg + 6 digits)
1) Additional 50.00nF range accuracy is not specified
2) Accuracies with film capacitor or better
3) Specified with battery voltage above 2.8V (approximately half full battery).
Accuracy decreases gradually to 12% rdg at low battery warning voltage of
approximately 2.4V
Transient protection: 6.5 kV (1.2/50 μs surge)
DC μA
Range Accuracy Burden Voltage
400.0μA ±( 2.0% rdg + 4 digits) 2.8mV/μA
2000μA ±( 1.2% rdg + 3 digits) 2.8mV/μA
Transient protection: 6.5 kV (1.2/50 μs surge)
AC μA (50Hz ~ 500Hz)
Range Accuracy Burden Voltage
400.0μA ±( 2.0% rdg + 5 digits) 2.8mV/μA
2000μA ±( 1.2% rdg + 5 digits) 2.8mV/μA
Transient protection: 6.5 kV (1.2/50 μs surge)
Type-K Temperature
Range Accuracy
-20 °C ~ 300 °C ±( 2% rdg + 3 °C)
301 °C ~ 537 °C ±( 3% rdg + 3 °C)
-4 °F ~ 572 °F ±( 2% rdg + 6 °F)
573 °F ~ 999 °F ±( 3% rdg + 6 °F)
Type-K thermocouple range & accuracy not included
