FEATURES
The Amprobe NCV-1000 series Non-Contact Voltage
(NCV) tester provides maximum safety and convenience
for detecting AC voltage without interrupting electrical
systems. Designed to conveniently fit in your shirt
pocket, the NCV-1000 series tester performs in indoor
and outdoor settings. Safety tested to the highest
category measurement, CAT IV 1000 V, as well as IP65
water and dust resistant, the NCV-1000 series is fit for
the toughest industrial applications.
• Non-contact voltage detection up to 1000 V AC
• Built-in flashlight (NCV-1030 and NCV-1040)
• Water and dust resistant - IP65 rated
• Audible (buzzer) and visual (LED) voltage indication
• On/off switch
• Auto power off (NCV-1030 and NCV-1040)
• CAT IV 1000 V safety rated
• Magnetic solenoid testing (NCV-1040)
• Low battery indication (NCV-1030 and NCV-1040)
NCV-1020 NCV-1030 NCV-1040
NCV Default
range
(AC)
50 to 1000 V 50 to 1000 V 50 to 1000 V
NCV High
Sensitivity
range (AC)
12 to 50 V
*
12 to 50 V
*
Magnetic
solenoid
testing
●
* Note: High sensitivity range is optimized for
12 to 50 V range with a maximum indication up
to 1000 V. Using the tester above 50 V in high
sensitivity range may affect polarity indication.
Your shipping carton includes a Tester, user manual
and 2 1.5 V AAA batteries (installed).
APPLICATIONS
• Detects the presence of AC voltage in cables,
circuit breakers, wall sockets, junction boxes,
fuses, extension cords and more.
• Tests voltage through wire insulation.
• Identifies cable breaks in wires, cords and
lighting systems connected in series.
• Identifies polarity (line vs. neutral) of receptacles
and cables. (Depending of the internal
construction and dimension of receptacles in
different countries this application may be
influenced.)
• Tests voltage without contact.
