6
Using the Flashlight
A flashlight is installed in the NCV-1030 and NCV-1040.
Activate the flashlight by pressing the button .
To switch OFF the flashlight press the button
again.
SPECIFICATIONS
Operating
Voltage Range
NCV-1020:
50-1000 Vac, 50-400 Hz
NCV-1030:
12-50 Vac, 50-1000 Vac, 50-400 Hz
NCV-1040:
12-50 Vac, 50-1000 Vac, 50-400 Hz
Voltage
Detection
default range
LED and buzzer indications at
approximately 5 mm (0.20 in)
distance from a wire carrying
230 Vac
Detection
of Magnetic
Field
NCV-1040:
approximately >2.5 mT
Measuring
category
CAT IV 1000V
Ingress
protection
IP65
Temperature
Range
32 °F to 104 °F (0 °C to 40 °C),
≤ 80% RH
Storage
Conditions
14 °F to 104 °F (-10 °C to 40 °C),
≤ 85% RH
Operating
Altitude
≤ 6561 ft (2000 m)
Duty Cycle Continuous
Power Supply 2 x 1.5 V LR03 AAA batteries
Current
Consumption
Approximately 80 mA
Dimensions
(L x W x H)
6.14 x 0.92 x 1.08 in
(156.2 x 23.5 x 27.5 mm)
Weight
(with
batteries
installed)
NCV-1020: Approx. 0.12 lb (58 g)
NCV-1030: Approx. 0.13 lb (60 g)
NCV-1040: Approx. 0.136 lb (62 g)
Safety
Compliance
IEC 61010-1 3rd Ed., UL 61010-1 3rd
Ed., UL 61010-2-030, CAN/CSA-C22.2
No.61010-1-12, CAN/CSA-C22.2 No.
61010-2-030-12 to CAT IV 1000 V,
Pollution degree 2, IP65
