MT-1002/702
• Detailed specications drawings for the MT-1002 are available to download from www.amx.com.
• Detailed specications drawings for the MT-702 are available to download from www.amx.com.
Connector Locations
USB peripherals (mouse, keyboard, etc.) may be connected to the USB port on the rear of the device. Updates to the device’s
rmware can also made via the USB port.
Note that FIG. 17 shows a MT-1002, but the connector locations are similar for all MT panels:
FIG. 17 MT-1002 Connector Location
USB Port
RJ-45 Port
