MSD-1001-L Specifications (Cont.)
EXTERNAL POWER
SUPPLY REQUIRED
Optimal performance requires use of one of the following AMX PoE power supplies (not
included):
• PS-POE-AF-TC, PoE Injector, 802.3AF Compliant (FG423-83)
• NXA-ENET8-2POE, Gigabit PoE Ethernet Switch (FG2178-63)
CERTIFICATIONS • FCC Part 15 Class B
• CE EN 55022
• CE EN 55024
• CE EN 60950-1
• IEC 60950-1
• C-Tick CISPR 22 Class B
• IC CISPR 22 Class B
• UL 60950-1
• VCCI CISPR 22 Class B
•RoHS
• WEEE
TOUCH SCREEN DISPLAY • Display Type: TFT Active Matrix Color LCD
• Display Size (WH): Landscape: 9.1" x 5.9" (230mm x 149mm), 10.8" (274mm) diagonal
• Viewable Area (WH): Landscape: 8.5" x 5.4" (217mm x 136mm ), 10.0" (256mm)
diagonal
• Resolution: Landscape: 1280x800
• Aspect Ratio: Landscape: 16:9
• Brightness: 350 cd/m2
• Contrast Ratio: 800:1
• Color Depth: 16.7M colors
• Illumination: LED
• Touch Overlay: Resistive
VIEWING ANGLE 85°/85°/85°/85° (Up/Down/Left/Right)
MEMORY • SDRAM: 512 MB
•Flash: 4 GB
• Maximum Project Size: 2.4 GB flash available to user
COMMUNICATIONS • Ethernet: 10/100 port, RJ-45 connector. Supported IP and IP-based protocols: UCP,
TCP, ICMP, ICSP, IGMP, DHCP, Telnet, FTP, DNS, RFB (for VNC), HTTP
• (1) USB host 2.0, Type A port: firmware upgrade, touch panel file transfer, JPEG image
viewer, HID peripherals
• Bluetooth®: Mouse/Keyboard: HID Profile v1.1, requires MXA-BT, Bluetooth USB
Adapter for Modero X/S Series Touch Panels (FG5968-19) and MXA-HST, Bluetooth
Handset for Modero X/S Touch Panels (FG5968-17)
VIDEO • Supported Video Codecs:
MPEG2-TS: MPEG-2 Main Profile@High Level up to 720p at 25 fps (decode)
MPEG-2-TS: H.264 High Profile@Layer 4, AAC-LC up to 720p at 25 fps (decode)
MJPEG up to 720p at 25 fps (decode)
• Supported Video Transport Streams: MPEG-TS for MPEG2 and H.264; HTTP for
MJPEG
• Max Number of Active Video Streams: One decode
AUDIO • Microphone: -42 dB ±3 dB sensitivity FET microphone
• Speakers: 4 ohm, 1.5 Watt, 500 Hz cutoff frequency
• Supported Audio Codecs:
MP2 Layer I and II, MP3 (8 kHz, 11.025 kHz, 12 kHz, 16 kHz, 22.05 kHz, 24 kHz, 32
kHz, 44.1 kHz, 48 kHz)
AAC-LC (8 kHz, 96 kHz)
G.711 with µLaw (VoIP encode/decode at 8 kHz)
• File Formats: WAV, MP3 (as part of touch panel file only - no USB storage)
• Intercom: Full Duplex VoIP, SIP v2.0 (supported with AMX-CSG)
To Next Page
