Modero X Series® Touch Panels
4
MXD/T-1900L-PAN 19.4" Modero X Series® Panoramic Touch Panels
MXT-1900L-PAN Specifications (Cont.)
Communications:
Ethernet: 10/100 port, RJ-45 connector.
USB: 3 - USB host 2.0, Type A ports.
Near Field Communications
(NFC):
Supports standards ISO/IEC 15693, ISO/IEC 14443A, ISO/IEC 14443B;
Unique Identifier (UID), Typical Range =.25”, Max = .5"
Bluetooth: HID Profile v1.1, Keyboard/Mouse Support, requires MXA-BT Bluetooth
Adaptor.
Video:
Streaming/File Formats: MPEG-TS for MPEG2; HTTP for MJPEG.
Video Conferencing: External application using on-board camera and microphone through
Micro-USB connection.
Audio:
Streaming/File Formats: WAV, MP3.
Intercom: Full Duplex VoIP, SIP v2.0 (supported with AMX-CSG).
Operating Environment: • Operating Temperature: 32° F to 104° F (0° C to 40° C)
• Storage Temperature: 4° F to 140° F (-20° C to 60° C)
• Humidity Operating: 20% to 85% RH
• Humidity Storage: 5% to 85% RH
Dimensions (HWD):
7" x 20 7/16” x 5 5/16” (177.8 mm x 519 mm x 134.6 mm)
Weight:
9.4 lbs (4.26 Kg)
Certifications: • FCC Part 15 Class B
• C-Tick CISPR 22 Class B
• CE EN 55022 Class B and EN 55024
• CB Scheme IEC 60950-1
Included Accessories: • MXT-1900L-PAN Installation Guide (93-5968-02)
• MXA-CLK Modero X Series Cleaning Kit (FG5968-16)
• 3.5mm Locking Captive Wire Connector (41-0002-SA)
• HPG-10 .75-inch HydraPort .75-IN. Grommet (FG570-01)
• Type A USB Covers (2)
• Tie Wrap for Power Source Ferrite
Other AMX Equipment: • PSN4.4 4.4AMP, 13.5VDCA5 Power Supply (FG423-45)
• MXA-USB-C USB Cover Kit (FG5968-18)
• MXA-BT Bluetooth USB Adaptor (FG5968-19)
