Modero X Series® Touch Panels
5
MXD/T-1900L-PAN 19.4" Modero X Series® Panoramic Touch Panels
Connector Locations
With the unit facing you, the two USB ports for peripherals are located on the rear right corner of the device
(FIG. 3). The power and Ethernet connectors, as well as an additional USB port and a 5-pin Micro-USB port,
are located on the bottom of the device.
In addition to its speaker, the MXT-1900L-PAN also utilizes its Micro-USB port for video output from camera
video and microphone output.
Memory
The MXT-1900L-PAN comes with 512 MB of SDRAM and 4 GB of Flash memory, neither of which can be
upgraded. A maximum of 2.4 GB is available to the user for projects.
Basic Operation
The MXT-1900L-PAN is operated using its integral touchscreen, as well as the Sleep button on the top of the
device (FIG. 1). If the device has gone into its Sleep Mode, a touch of the touchscreen or of the Sleep button
will reactivate it.
Powering on the MXT-1900L-PAN
The MXT-1900L-PAN may be powered on by touching and holding the Sleep button on the top of the device.
Microphone
The MXT-1900L-PAN contains a built-in microphone above the touch screen for video and audio
conferencing capabilities. This microphone is concealed by the casing.
Audio/Video Capabilities
The MXT-1900L-PAN has the capability of displaying multiple JPEG and PNG files at one time. The device
also supports streaming motion JPEG video (of the sort used by many IP and Web cameras), as well as MP3
and WAV audio files.
MXT-1900L-PAN-NC
The MXT-1900L-PAN-NC (FG5968-21) No Comm touch panel does not have camera, microphone, or NFC
capability. It otherwise has all of the functionality of the MXT-1900L-PAN panel.
FIG. 3 MXT-1900L-PAN USB port location
