MXD/T-1900L-PAN 19.4" Modero X Series® Panoramic Touch Panels
Memory
The MXD-1900L-PAN comes with 512 MB of SDRAM and 4 GB of Flash memory, neither of which can be
upgraded. A maximum of 2.4 GB is available to the user for projects.
Basic Operation
The MXD-1900L-PAN is operated using its integral touchscreen, as well as the Sleep button on the top of the
device (FIG. 1). If the device has gone into its Sleep Mode, a touch of the touchscreen or of the Sleep button
will reactivate it.
Powering on the MXD-1900L-PAN
The MXD-1900L-PAN may be powered on by touching and holding the Sleep button on the top of the device.
Microphone
The MXD-1900L-PAN contains a built-in microphone above the touch screen for video and audio
conferencing capabilities. This microphone is concealed by the casing.
Audio/Video Capabilities
The MXD-1900L-PAN has the capability of displaying multiple JPEG and PNG files at one time. The device
also supports streaming motion JPEG video (of the sort used by many IP and Web cameras), as well as MP3
and WAV audio files.
MXD-1900L-PAN Specifications (Cont.)
Communications:
Ethernet: 10/100 port, RJ-45 connector
USB: 2 - USB host 2.0, Type A ports
Near Field Communications
(NFC):
Supports standards ISO/IEC 15693, ISO/IEC 14443A,
ISO/IEC 14443B; Unique Identifier (UID), Typical Range = .25", Max = .5"
Bluetooth: HID Profile v1.1, Keyboard/Mouse Support, requires MXA-BT Bluetooth Adap-
tor
Video:
Streaming/File Formats: MPEG-TS for MPEG2; HTTP for MJPEG
Video Conferencing: External application using on-board camera and microphone through
Micro-USB connection.
Audio:
Streaming/File Formats: WAV, MP3
Intercom: Full Duplex VoIP, SIP v2.0 (supported with AMX-CSG)
Operating Environment: • Operating Temperature: 32° F to 104° F (0° C to 40° C)
• Storage Temperature: 4° F to 140° F (-20° C to 60° C)
• Humidity Operating: 20% to 85% RH
• Humidity Storage: 5% to 85% RH
Dimensions (HWD):
• Landscape: 6.9" x 20.4" x 0.7" (175 mm x 519 mm x 19 mm)
• Portrait: 20.4" x 6.9" x 0.7" (519 mm x 175 mm x 19 mm)
Weight:
7.0 lbs (3.18 Kg)
Certifications: • FCC Part 15 Class B
• C-Tick CISPR 22 Class B
• CE EN 55022 Class B and EN 55024
• CB Scheme IEC 60950-1
Included Accessories: • MXD-1900L-PAN Installation Template (68-5968-02)
• MXA-CLK Modero X Series Cleaning Kit (FG5968-16)
• 3.5mm Locking Captive Wire Connector (41-0002-SA)
Other AMX Equipment • PSN4.4 4.4AMP, 13.5VDCA5 Power Supply (FG423-45)
• MXA-BT Bluetooth USB Adaptor (FG5968-19)
• MXA-USB-C USB Cover Kit (FG5968-18)
• CB-MXP Panoramic Rough-In Box (FG039-15)
