Modero X Series® Touch Panels
7
MXD/T-1900L-PAN 19.4" Modero X Series® Panoramic Touch Panels
MXD-1900L-PAN Specifications
Power Requirements: 12VDC, 4.4A: 2-pin, locking 3.5mm captive wire connector
Power Consumption: • Constant current: 2.7A (32W) @ 12VDC
• Start up current: 4.05A (48W) @ 12VDC
• Standby current: 0.3A (3.1W) @ 12VDC
• Recommended minimum power supply: 4.4A (PSN4.4)
Front Panel Components:
NFC Transceiver: Antenna and transceiver for Near Field Communications device detection and
interaction.
Light Sensor: Photosensitive light detector for automatic adjustment of the panel brightness.
Motion Sensor: Proximity detector to wake the panel when it is approached.
• Typical Range: 1 foot (30.48 cm)
• Maximum Range: 3 feet (91.44 cm)
• Range width: 10 degrees
LED Indicator: Camera active indicator (landscape only)
Sleep Button: Single button on edge of panel for placing panel in sleep mode, for powering off
panel, and for access to Settings pages.
Microphone: -42dB +- 3dB sensitivity FET microphone
Speakers: 4 ohm, 2 Watt, 300Hz cutoff frequency
Camera (landscape only): HD 720P camera for video conferencing/video chat support.
Rear Panel Components:
Ethernet 10/100 Port: 10/100 Base-T RJ-45 connector for Ethernet connectivity.
Power Port: Locking 2-Pin, 3.5mm captive wire connector.
Micro-USB Port: 5-pin Micro-USB connector used for video output from
camera video (Landscape Only) and microphone output only.
USB Ports (2): USB connectors used for keyboard and mouse connections, or for firmware
uploads. Side port may require right angle mating connector (not included) for
some configurations.
Touch Panel Display:
Display Type: TFT Active Matrix Color LCD with In-Plane Switching (IPS) technology.
Display Size
(W x H):
• Landscape: 20.4" x 6.9" (519 mm x 175 mm)
• Portrait: 6.9" x 20.4" (175 mm x 519 mm)
• 20.4" (518 mm) diagonal
Viewable Area
(W x H):
• Landscape: 18.7" x 5.9" (475 mm x 151 mm)
• Portrait: 5.9" x 18.7" (151 mm x 475 mm)
• 19.4" (493 mm) diagonal
Viewing Angle: • Vertical: ± 89°
• Horizontal: ± 89°
Screen Resolution
(W x H):
• Landscape: 1920x530
• Portrait: 530x1920
Aspect Ratio
(W x H):
• Landscape: 18:5
• Portrait: 5:18
Brightness: 350 cd/m2
Contrast Ratio: 1000:1
Color Depth: 16,7M colors
Backlight Type: LED
Touch Overlay: Projected Capacitive; Multi-touch support, 3 simultaneous max.
